Quantity
Price
Total price
1
$25.1790
$25.1790
10
$22.0500
$220.5000
25
$21.0980
$527.4500
50
$20.4120
$1,020.6000
100
$19.7330
$1,973.3000
250
$18.6480
$4,662.0000
| TYPE | DESCRIPTION |
| Mfr | ODU |
| Series | ODU MEDI-SNAP® |
| Package | Bulk |
| Product Status | ACTIVE |
| Features | Backshell, Strain Relief |
| Connector Type | Receptacle, Female Sockets |
| Color | Gray |
| Current Rating (Amps) | 2.75A |
| Mounting Type | Free Hanging (In-Line) |
| Shielding | Unshielded |
| Number of Positions | 12 |
| Orientation | 0 |
| Shell Size - Insert | 1 |
| Operating Temperature | -50°C ~ 120°C |
| Applications | Industrial, Medical, Testing Equipment & Measurement |
| Fastening Type | Push-Pull, Detent Lock |
| Termination | Solder Cup |
| Ingress Protection | IP50 - Dust Protected |
| Cable Opening | 0.106" ~ 0.154" (2.70mm ~ 3.90mm) |
| Contact Material | Brass |
| Contact Finish - Mating | Gold |
| Shell Material | Polysulfone (PSU) |
| Insert Material | Polyetheretherketone (PEEK) |
| Backshell Material, Plating | Polysulfone (PSU) |
| Primary Material | Plastic |
